S1-X EM+MF
> Waterproof, conforms to IP66
> One relay, 1000 users
> Access modes: Card, PIN, Card + PIN, Multi Cards
> Card type: 125KHz EM & 13.56MHz Mifare (NXP Mifare, Mifare Plus, DesFire, Mifare Pro,
Mifare UltraLight, Mifare Class 4K, NFC and CPU cards)
> PIN length: 4~6 digits
> Wiegand 26~44, 56, 58 bits input & output
> User data can be transferred by Wiegand line
> Pulse mode, toggle mode
> 2pcs devices support interlock for two doors
The S1-X is a single door multifunction standalone access controller or a Wiegand output reader.
It supports multi access modes, and it has extra features including block enrollment, interlocked...etc.
